SIC MOS選型表

產品詳情

SiC Mosfet
Product Name	Package	Blocking Voltage(V)	Current Rating(A)	Generation	Rdson(mΩ)@25℃	Gate Charge Total Qg（nC）	Output Capacitance Coss(pF)	Total Power Dissipation PTOT (W)
YJD2065100NCFGH	TO-247-4L	650	32	GH	100	66	105	166
YJD2065100NCTGH	TO-247AB	650	32	GH	100	66	105	166
YJD2065200B7GH	TO-263-7L	650	19	GH	200	43	67	120
YJD2065200BGH	D2PAK	650	19	GH	200	43	67	120
YJD2065200NCFGH	TO-247-4L	650	16	GH	200	43	67	89
YJD2065200NCTGH	TO-247AB	650	16	GH	200	43	67	89
YJD206520NCFGH	TO-247-4L	650	107	GH	20	287	359	375
YJD206520NCTGH	TO-247AB	650	107	GH	20	287	359	375
YJD206520TLGH	TOLL	650	86.5	GH	20	300.1	352	208.3
YJD206525NCFGG2	TO-247-4L	650	60	Gen2	25	137	118	187
YJD206525NCFGH	TO-247-4L	650	107	GH	25	275	358	375
YJD206525NCTGH	TO-247AB	650	107	GH	25	275	358	375
YJD206525T2GH	T2PAK	650	155	GH	25	275	358	780
YJD206550NCFGG2	TO-247-4L	650	33	Gen2	50	82	56	131
YJD206550NCFGH	TO-247-4L	650	60	GH	50	121	208	250
YJD206550NCTGH	TO-247AB	650	60	GH	50	121	208	250
YJD206560NCFGH	TO-247-4L	650	60	GH	60	116	205	250
YJD206560NCTGH	TO-247AB	650	60	GH	60	116	205	250
YJD2120120B7GH	TO-263-7L	1200	24.5	GH	120	67	56	166
YJD2120120BGH	D2PAK	1200	24.5	GH	120	67	56	166
YJD2120120NCFGH	TO-247-4L	1200	24	GH	120	67	56	166
YJD2120120NCTGH	TO-247AB	1200	24	GH	120	67	56	166
YJD2120240B7GH	TO-263-7L	1200	13.5	GH	240	47	36	105
YJD2120240BGH	D2PAK	1200	13.5	GH	240	47	36	105
YJD2120240NCFGH	TO-247-4L	1200	13.5	GH	240	47	36	105
YJD2120240NCTGH	TO-247AB	1200	13.5	GH	240	47	36	105
YJD212025NCFGH	TO-247-4L	1200	95	GH	25	366	238	450
YJD212025NCTGH	TO-247-4L	1200	95	GH	25	366	238	450
YJD212030NCFG2	TO-247-4L	1200	68	Gen2	30	127	119	333
YJD212030NCFGH	TO-247-4L	1200	78	GH	30	305	198	375
YJD212030NCTG2	TO-247AB	1200	68	Gen2	30	127	119	333
YJD212030NCTGH	TO-247AB	1200	78	GH	30	305	198	375
YJD212040NCFG1	TO-247-4L	1200	63	Gen1	40	120	141	300
YJD212040NCFG2	TO-247-4L	1200	66	Gen2	33	116	127	333
YJD212040NCFGH	TO-247-4L	1200	62	GH	40	229	149	326
YJD212040NCTG1	TO-247AB	1200	63	Gen1	40	120	141	300
YJD212040NCTG2	TO-247AB	1200	66	Gen2	33	116	127	333
YJD212040NCTGH	TO-247AB	1200	62	GH	40	229	149	326
YJD212040NCTGH2	TO-247AB	1200	78	GH	40	280	195	375
YJD212040T2GH	T2PAK	1200	85	GH	40	229	149	600
YJD212060NCFGH	TO-247-4L	1200	44.5	GH	60	129	115	250
YJD212060NCTGH	TO-247AB	1200	44.5	GH	60	129	115	250
YJD212060TLGH	TOLL	1200	42.5	GH	60	117	97.35	234.4
YJD212080NCFG1	TO-247-4L	1200	39	Gen1	77	41	58	223
YJD212080NCFGH	TO-247-4L	1200	33	GH	80	131	85	224
YJD212080NCTG1	TO-247AB	1200	38	Gen1	77	41	58	220
YJD212080NCTGH	TO-247AB	1200	33	GH	80	131	85	224
YJD212080TLG1	TOLL	1200	39.5	Gen1	75	48	56.3	228
YJD217045NCFGH	TO-247-4L	1700	55	GH	45	304	145	375
YJD217045NCTGH	TO-247AB	1700	55	GH	45	304	145	375
YJD2170500B7GH	TO-263-7L	1700	8.3	GH	500	34.1	21	94
YJD2170500BGH	TO-263-2L	1700	8.3	GH	480	34.1	21	94
YJD2170500NCTGH	TO-247AB	1700	8.3	GH	500	30.4	21	89
